- Size: 16000X3000X1600
- Place of Origin: CHINA
- Brand Name: best
- Model Number: jt9402xxy
- Weight: 10500.000 kg
1.As one of our best selling products,it's main beam is well welded by the submerged arc machine and well treated by the shot blasting machine,
2.This type 50tons-70tons payload low bed semi trailer is wided used for carrying excvavtor ,road roller,containers and other machines,
3.Since having a strong design team for low bed semi trailer , more than 1000 workers for prodution,and the quality inspection team, you are always served by the right and high quality products, and welcome you visit our company and factory at anytime.
specification
Gross Weight | About 5.5 tons or 3.2 tons |
Outer side dimension (mm) | 12450 × 2490 × 1557 (three or two axles) 40FT 7160 × 2490 × 1557 (two axles) 20FT |
Loading Capacity (Ton) | ≤ 45 T (40FT) ≤30T (20FT) |
AXLES | 13 T /PER , FUWA Brand, BPW Brand, or Huajing Brand |
Tire | 12.00R22.5 or 315/80R22.5 China Brand or According to Customer requirement |
Rim | 9.00-22.5 China Brand |
Suspension | Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand ) |
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type |
Support leg | JOST brand D200T or China brand 28Tons (Double speed) |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm ; Material is Q345B Steel . |
Side beam | 16mm or 18mm channel steel ( Material is Q235steel ). |
Brake chamber | WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber(TKL brand); one piece of 45L air tanks |
Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) |
Valve | WABCO valve |
ABS | Optional |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways (7 wire harness) |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping Terms: | Transport by bulk cargo carrier, RORO or 40HQ container. |
- Size: 16000X3000X1600
- Place of Origin: CHINA
- Brand Name: best
- Model Number: jt9402xxy
- Weight: 10500.000 kg
| Use: | Truck Trailer | Type: | Semi-Trailer | Material: | Steel |
| Certification: | ISO9001,3C, ISO9001 3C | Size: | 16000*2800*1660 | OEM No.: | 3708322800116 |
| Max Payload: | 50T | Place of Origin: | Shandong, China (Mainland) | Brand Name: | BEST |
| Model Number: | BET9400TDP | Condition: | New | Axle: | 3axles,FUWA or BPW brand |
| King pin: | 2" or 3.5" | Steel spring: | 10 pieces per axles | Support legs: | JOSTD200Tor Tongyada 28T |
| Axle number: | Three | Axle specs.: | FUWA Brand | Tool box: | One or more |
| Colour: | Any colour can be choose |
