- Place of Origin: LIANGSHAN
- Brand Name: best
- Model Number: BS9600TJZG
Tare Weight | About 7.5T |
Dimension | 12500mm*2500mm*1550mm |
Loading Capacity (T) | 50 T |
Axle | 3 axles / 2axles, 13 T/16T/20T BPW / FUWA / Huajing /Jinsheng |
Rim | 9.00-22.5 (special for export market) |
Tire | 12R22.5 Deshenglong brand 13pieces/ 9 pieces |
Suspension | Air suspension ( Mechanical America Type optional/ bogie suspension) |
Spring leaf | 90(W)mm*13(Thick)mm*10 Layer |
King pin | brand JOST optional |
Support leg | Jost brand optional |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel |
Side beam | Q235 16# channel steel |
Platform | 3mm diamond platform |
Side wall | Height is 600mm, you can choose freely. |
Brake chamber | WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber(TKL brand); One piece of 45L air tanks |
ABS | Without (optional) |
Twist Locks | 8 / 12 pieces (Lifting type) |
Valve | WABCO valve |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways (7 wire harness) |
Tool box | 1 piece:equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive primer, 2 coats of final paint |
Shipping Terms: | By bulk cargo carrier, RORO or 40HQ container |
